Rapid targeting with true 1x low mag setting. Versatile 8x zoom ratio for point blank to extended ranges. This is Super Eight…..
Specifications
Magnification Range: 1-8x
Field of View @ 100y: 112 – 16ft
Eye Relief: 89mm
Fixed Parallax Distance: 100m
Minimum Focus Distance @ 8x: +/- 25 Yards
Minimum Focus Distance @ 6x: +/- 18 Yards
Total Elevation Adjustment Range: 30.0 MRAD
Adjustment Value Per Click: 0.1 MRAD
Adjustment Per Turn: 10.0 MRAD
Reticle Choice 1: B22i MilBox (Red Illuminated). Order Code S82. B22i MilBox Reticle (PDF)
Total Length: 252mm
Weight: 480g
Tube Diameter: 30mm
Construction: 1 Piece Tube/Saddle/Objective
Objective Lens Diameter: 24mm
Outer Objective Diameter: 30mm
Outer Ocular Diameter: 42.9mm
Mounting Length & Exterior Dimensions : (PDF Diagram here)
Flip Up Lens Covers: Yes, Supplied
Objective end. Contains the objective lens assembly and objective lens hood. Both the sunshade and objective cover thread into the objective hood
Elevation and Windage turrets. These are used to adjust the position of the reticle and ’zero in’.
Illuminated Reticle Control and Battery Compartment
Saddle section. This houses the elevation, windage and side parallax turrets. To the front and rear of the saddle section is the 30mm main tube
Elevation and Windage turrets. These are used to adjust the position of the reticle and ’zero in’
Magnification ring. This rotates to adjust the magnification setting
Eyepiece section
Ocular end. Contains the ocular lens assembly. This is threaded for adjustment, sometimes referred to diopter correction or ‘European style fast focus eyepiece’.
- Equipment Overview available for download here
- Nitrogen Purged.
- Waterproof Tested.
- Recoil Tested up to and including .338LM. (And we say .338LM as in our experience these tend to do more damage than the .50BMG)
- Hand Tested and Quality Control passed in the UK.
- Global Warranty.
